Home Products Vacuum Pressure Impregnation Vacuum Impregnation Machine We are among the eminent names in the industry for manufacturing and supplying Vacuum Pressure Impregnation Machine.The offered machine is effective in impregnating deep voids of winding for increasing the working ability of wind turbines, generators, transformers, capacitors and coils.This machine is robust in terms of construction as well.Features:Robust constructionEffective impregnationUser-friendly Other details:Electrical current that rows through a coil always causes a vibration of the entire winding called transformer humming or microphonic effect and generates heat which reduces the life of the windings.Voids in the windings also accelerates the degradation of insulation material and causes the transformer to fail prematurely.VPI Plant produces a better insulation for better environmental protection and moisture resistance.The removal of air voids from the windings assures longer electrical life.These plants are specially used to force an Impregnate / Varnish into the deep voids of winding for better penetration and reduce the air gapsThese plant are used for insulation treatment of following electrical Product:H.V motors and generatorsWind turbinesDry type transformersInsulation material of cablePower capacitorH.

T coils for automobile industries Categorization:VPI plant for motor windingsVPI plant for transformers Technical Specification:Impregnation tank:Operating pressure: 0 – 10 kg/sq cm2Chamber Size range: Dia 500 mm to 3000 mmType of clampingManual clampingBayonet clampingAccessories mountingSafety valvePressure relief valveVacuum breakerSight and light arrangement Storage tank:Storage tank specially designed to store varnish, oils or liquids as per customer need or varnish manufacturer specified.Heating system to maintain temperature ranging from 25 C to 80 CCooling system for to maintain temperature of 0 c to 25 C100 mm rock wool insulation used to avoid heat transfer Stirrer:A stirrer with 3 nos Airfoil shaped blades is provided in order to reduce temperature gradient of varnish between side walls and a center of tankStirrer speed – 70 rpmBearing housing and stool provided in order to reduce friction, noise and for ease operationPressure system:For pressure either the line can be taken from existing compressor unit or will be provided us as per customer requirementMoisture separatorSafety devicesPressure regulator Control Panel:Control panel will be provided as per customer requirementManually operatedPLC based Vacuum Pressure Impregnation We are among the recognized names in the industry for manufacturing and supplying Vacuum Pressure Impregnation plant to a wide clientele.

This plant is used for impregnating a gamut of machines including wind turbines, electric coils, generators, transformers and capacitors.This plant is made in tune with the industry standards and provides ultimate impregnating solutions.Features: Energy efficientLow maintenanceLonger service lifeAdvantages of Using VPI Plant: Longer Electrical LifeBetter Thermal EnduranceLow hot spot temperaturesLow temperature riseThese plant are used for insulation treatment of following electrical product: H.V motors and generators Wind turbines Dry type transformers Insulation material of cable Power capacitor H.T coils for automobile industriesGeneral Process: The windings are lowered into the autoclave.möbel abverkauf schweizWithin the autoclave the windings are subjected to high vacuumThe varnish is transferred from reservoir to the autoclave & the vacuum in the autoclave is maintained until the windings are thoroughly impregnatedThe Vacuum is released and dry air pressure is applied for certain periodUsing the same pressure varnish is transferred to the reservoir Plant Categorization: Hydraulic lid lifting & bayonet clamping systemManual Type control console / Fully automatic equipped with PLC & SCADA or HMIDHeating System to a Autoclave / Storage tankStorage tank equipped with Chilling Plant & Stirrer as per customer need or depending on varnish properties X Products Showcase Gallery Home  | Profile   |  Products  |  Site Map  | Contact Us |   Mobile Site © .gebrauchte möbel freiburg littenweiler
